| Place of Origin: | China, Jiangsu, Changzhou |
|---|---|
| Brand Name: | YUESEN |
| Certification: | ISO2000, RoHS, REACH |
| Model Number: | YD36-20B-16 |
| Minimum Order Quantity: | 10kpcs |
| Price: | $0.5/pcs |
| Packaging Details: | Carton size: 45*30*36cm |
| Delivery Time: | 2-4 weeks |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 1-1.5million/month |
| Size: | 36mm | Power: | 1.4W |
|---|---|---|---|
| Impedance: | 16ohm | Sound Pressure Level: | 82±2dB |
| Frequency Response: | F0-5.0kHz | Product Name: | Mylar Speaker |
| High Light: | 16Ohm Micro Precision Speaker,Mylar Micro Precision Speaker,16Ohm Mylar Precision Speaker |
||
YD36-20B-16, Mylar Speaker commonly used accessories, 1.4W, 16ohm
We are a high-tech enterprise which integrates research, design, production and sales. Our products are widely used for TV, Mobile devices such as notebook, GPS, mobile DVD and so on.
General Specifications:
| Dimensions | 36mm |
| Rated Input Power | 1.4W |
| Maximum Input Power | 2.1W |
| Sound Pressure Level | 82±2dB at 1.0, 1.2,1.5,2.0,2.5kHz |
| Impedance | 16Ω±15%(at 1.0kHz, 1V) |
| Frequency Response | F0~5.0kHz(-10dB) |
| Noise | It shall be normal. Sine wave 4.73V. |
| Operation | It shall be normal. Program source 1.4W |
| Load Test |
Shall be normal after test. Input Power: 1.4W White Noise Duration: 100 hours |
| Humidity Test |
Shall be normal after test. Temperature: 40℃±2℃ Relative Humidity: 90~95%RH Duration: 48 hours |
| Heat Test |
Shall be normal after test. Temperature: 55±2℃ Duartion: 16 hours |
| Magnet |
Ф12.5×1.6 NdFeB(material size) |
| Total Flux |
Max well |
| Polarization |
1.The terminal down ward(-)side(negative)pde. 2.Rerminal with(+) or red dotlabeled a positive. |
| Net Weight | 8.8±0.5g |
Drawing:
Product Processing:
