IP67 Vehicle Reverse Alarm White Sound Backup Alarm Multi Frequency

Basic Information
Place of Origin: CHINA
Brand Name: YUESONIC
Certification: CE,Eark
Model Number: YS-B73W
Minimum Order Quantity: 20 PCs
Price: USD15-USD 30/pc
Packaging Details: Individual neutral box, 20 pcs per carton
Delivery Time: 2-4 weeks
Payment Terms: L/C, T/T, D/P, Western Union
Supply Ability: 5000 Pcs/ Month
Detail Information
MATERIAL: Nylon VOLTAGE: 12-24V
OUTPUT: 90 To 100dB CURRENT: MAX 0.6A
TEMPERATURE: -40 To 85℃ FREQUENCY: Multi Frequency
SIZE: 127.5*79*82mm TYPE: Vehicle Reverse Alarm
High Light:

back up beeper sound

,

reverse beeper


Product Description

IP67 vehicle use beep sound real speech white noise vehicle reverse alarm



General specifications:



Output level 90 -100dB at 1.2M
Voltage 12-24VDC
Current drain less than 0.6A
temperature range -40 to 85 degree C
Frequency multi frequency
Duty cycle n/a
weight 300g ± 10%
Dimensions 127.5*79*82mm



Applications:

For cars, trucks, construction machinery, with 12V and 24VDC system, made for heavy duty applications in medium or high noise area.

With white noise sound, which is kind of multi frequency sound,  much safer than beep sounds, and is less annoying



Main features:

 Silent mode /night mode Warning could be cancelled by double engage into reverse gear, much safer and less noise pollution contribute to community

Nylon housing Designed to meet all hash conditions, provide splendid durability

IP68 Fully sealed with epoxy, well protected fagainst dust, moisture and vibration

Polarity protection It will not be damaged even you connect the polarity wrong

Easy to install and many connectors optional

Long warranty 24 months or longer

RoHS and CE



Similar products:

with same housing

P/N Voltage Output  Remark
YS-B71 12-24V 100dB beep sound
YS-B72 12-24V vary on sounds used bespoken message
YS-B73 12-24V 90-100dB white noise, with silent mode



Alarms of different housings

wire connection version ot studs version available for some housings

Connctors optional for wire connection versions

beep sound, white noise sound, vocal messages available for some models

Intelligent alarms with beep sound, white noise sound available.

Intelligent alarms with night mode, silent mode avaible.



IP67 Vehicle Reverse Alarm White Sound Backup Alarm Multi Frequency 0



Quick details for all series alarms

Series Size Sound Remark
B00 127*70*73.5mm beep sound intelligent models available
B10 dia 60*46.3mm beep sound
B20 103.5*40.5*71mm beep, white noise, bespoken message intelligent models available
B30 103*44.5*68mm beep, white noise, bespoken message intelligent models available
B40 129*69*74mm beep sound, bespoken message manual adjustable available
B50 102*44.5*69.5mm beep, white noise, bespoken message intelligent models available
B60 127*95*77mm beep, white noise, bespoken message intelligent models available
B70 127.5*79*82mm beep, white noise, bespoken message models with night mode available
B80 S 105*71.8*70mm beep, white noise, bespoken message models with night mode available
B80 L 130*76*88mm beep, white noise, bespoken message models with night mode available
BJ 58*30*59.5mm beep, white noise, bespoken message
B90   beep, white noise, bespoken message models with night mode available







More information about the alarm:

IP67 Vehicle Reverse Alarm White Sound Backup Alarm Multi Frequency 1

Alarm drawing, sizes in mm



IP67 Vehicle Reverse Alarm White Sound Backup Alarm Multi Frequency 2

alarm production line, with operation instruction for all positions







Alarm in production test, to have a better quality





IP67 Vehicle Reverse Alarm White Sound Backup Alarm Multi Frequency 3

Alarm Lab tests, including general specs tests, enviromental tests, reliabity tests, to make sure alarms well designed, will work well as we design it.



feel free to let me know if you want to know more about our products and factory.
